ArcGlide THC Instruction Manual 806450 267
A – ArcGlide THC Serial Communication Protocol
17 ERR 17 RETRACT TIMEOUT 4 ERR-Motion FAIL
18 ERR 18 SAMPLED ARC VOLTS 10 ERR-Machine Cable Missing
19 ERR 19 EXCESS PLATE CONTACT 3 ERR-Lifter not installed
20 ERR 20 PLASMA SUPPLY 11 ERR-Plasma Cable Missing
21 ERR 21 OHMIC TIP SENSE 3 ERR-Lifter not installed
22 ERR 36 CRITICAL ERROR 10 ERR-Machine Cable Missing
23 ERR 23 INPUT VOLTAGE LOW 9 ERR-Motor Current Fault
24 ERR 24 INPUT VOLTAGE HIGH 9 ERR-Motor Current Fault
25 ERR 25 OVER-TEMPERATURE 9 ERR-Motor Current Fault
26 ERR 26 MOTOR DRIVE 9 ERR-Motor Current Fault
27 ERR 27 INTERLOCK TRIPPED 10 ERR-Machine Cable Missing
28 ERR 28 BREAKAWAY TRIPPED 3 ERR-Lifter not installed
29 ERR 29 FIELD SUPPLY FAILED 9 ERR-Motor Current Fault
30 ERR 30 STALL CALIBRATION 8 ERR-Cycle Start ON at Init
31 ERR 31 NO HYPERNET CONNECTION 6 ERR-InterProcessor Comm Fail
32 ERR 32 LOST CNC HYPERNET 6 ERR-InterProcessor Comm Fail
33 ERR 33 LOST HMI HYPERNET 6 ERR-InterProcessor Comm Fail
34 ERR 34 ENCODER OVERFLOW 4 ERR-Motion FAIL
35 ERR 35 ENCODER UNDERFLOW 4 ERR-Motion FAIL
36 ERR 36 HYPERNET ADDRESSING 6 ERR-InterProcessor Comm Fail
37 ERR 37 SOFTWARE ERROR 5 ERR-Watchdog timeout FAIL
38 ERR 38 SOFTWARE LOOP TIME 5 ERR-Watchdog timeout FAIL
39 ERR 39 SOFTWARE UNDEF DISPLAY 5 ERR-Watchdog timeout FAIL
40 ERR 40 SOFTWARE ANALOG INPUT 5 ERR-Watchdog timeout FAIL
41 ERR 41 PROTOCOL MISMATCH 6 ERR-InterProcessor Comm Fail
42 ERR 42 LOST PAC HYPERNET 6 ERR-InterProcessor Comm Fail
ArcGlide Command THC
Error Code Error Message Error Code Description
