ArcGlide THC Instruction Manual 806450 59

2–Installation

System description for a Hypernet configuration

Figure 11 shows the cable and signal connections in a Hypernet communication configuration.



Hypernet cables transmit serial communication.

Figure 11

CNC with Hypernet

HPR plasma system

with Hypernet

ArcGlide lifter

HMI (optional)

Industrial Ethernet

switch

ArcGlide control module

Key:

Hypernet connection

– – – – – –

Discrete connection

——————
