ArcGlide THC Instruction Manual 806450 187
4 – Maintenance
No No
Verify the cut speed
in the cut chart
equals the set
program speed.
Verify the speed
control on the
operator console is
set to 100%.
Yes Is travel speed too
slow?
Is the workpiece
warping?
Yes Verify that the
workpiece is not
bowing while
cutting.
Turn off Nozzle
Contact Cutting.
No
Verify that Torch
Height Disable is
turning on when
cutting corners or
small radii.
Yes Is Torch Height
Disable working?
No
On a Hypertherm
CNC, check the
Torch Height Disable
settings on the
Speeds screen.
Verify that Torch
Height Disable
speed is the correct
percentage of cut
speed.
Yes Is Torch Height
Disable supported
by the CNC?
