Hypertherm ArcGlide THC User Manual

216 ArcGlide THC Instruction Manual 806450
4 – Maintenance
J1 Board interconnects
Pin No. Signal Pin No. Signal
1 CNC Cycle Start input 2 CNC IHS Complete output
3 CNC IHS Disable input 4 CNC Retract Complete output
5 CNC AVC Disable input 6 CNC Machine Motion output
7 CNC IHS Sync input 8 CNC Error output
9 +5 VDC 10 Ground
11 CNC spare 1 input (Do not use) 12 CNC Breakaway output
13 CNC spare 2 input (Do not use) 14 CNC spare output
15 Interlock 16 CNC Dry Inputs 24 V
17 Not connected 18 Not connected
19 +5 VDC 20 Ground
21 Plasma Motion input 22 Plasma Corner output
23 Plasma Error input 24 Plasma Pierce output
25 Plasma Ramp Error input 26 Plasma Hold output
27 Plasma Not Ready input 28 Plasma Start output
29 +5 VDC 30 Ground
31 Plasma spare input 32 Plasma spare output
33 Plasma RS-422 RX 34 Plasma RS-422 Tx
35 Not connected 36 Plasma Dry Inputs 24 V
37 Lifter Station Enable 38 Plasma Remote On output
39 +5 VDC 40 Ground
41 Lifter Lower Limit input 42 Lifter Brake output
43 Lifter Upper Limit input 44 Not connected
45 Lifter Breakaway input 46 Not connected
47 Lifter Manual Up input 48 Not connected
49 +5 VDC 50
Ground
51 Lifter Manual Down input 52 Operator console Enabled output
53 Lifter Change Consumable 54 Operator console Error output
55 Encoder A 56 Operator console spare output
57 Encoder B 58 Not connected
59 +5 VDC 60 Ground
61 Operator console Disable input 62 1/50 Arc V -
63 Operator console Select input 64 1/50 Arc V +
65 Operator console Torch Up input 66 Ohmic contact sense -
67 Operator console Torch Down input 68 Ohmic contact sense common
69 +5 VDC 70 Ground
71 Operator console spare input 72 Power good low active
73 Not connected 74 Line Volts
75 Not connected 76 Actual current
77 Not connected 78 Not connected
79 +5 VDC 80 Ground
