Hypertherm ArcGlide THC

ArcGlide THC Instruction Manual 806450 223
4 – Maintenance
J8 Hypernet
Pin No. Signal
1 Tx + (transmit data +)
2 Tx - (transmit data -)
3 Rx + (receive data +)
4 Not connected
5 Not connected
6 Rx - (receive data -)
7 Not connected
8 Not connected
J11 +5 V power
Pin No. Signal
1 +5 VDC
2 Ground
3 Common
4 Not connected
