ArcGlide THC Instruction Manual 806450 227
4 – Maintenance
J5 Plasma I/O cable (blue)
Pin No. Signal Pin No. Signal
1 RS-422 Rx - 2 RS-422 Rx +
3 RS-422 Tx - 4 RS-422 Tx +
5 RS-422 common 6 Motion input +
7 Input common - 8 Error input +
9 Input common - 10 Rampdown error input +
11 Input common - 12 Not ready input +
13 Input common - 14 Spare input +
15 Input common - 16 Corner output A
17 Corner output B 18 Pierce output A
19 Pierce output B 20 Hold output A
21 Hold output B 22 Start output A
23 Start output B 24 Spare output A
25 Spare output B 26 Remote on output A
27 Remote on output B 28 Common
29 Common 30 Common
31 +24 VDC 32 +24 VDC
33 +24 VDC 34 1/50 Arc voltage +
35 1/50 Arc voltage - 36 Not connected
37 – 50 Not connected
