ArcGlide THC Instruction Manual 806450 277
B – ArcGlide THC Serial Communication Installation
Figure 51
1b
2a
3
4a
4b
2b
1a
DB37 male
DB37 female
DB37 female
DB37 male
DB50 male
Discrete plasma interface
board (141094)
J5
DB37 (female)
CNC
Plasma system
Command THC CNC I/O cable or
customer-supplied CNC I/O cable
Customer-supplied connector
Z adapter cable
(223253)
Command THC
plasma I/O cable or
customer-supplied
plasma I/O cable
Customer-supplied
serial cable
RS-422 ports
Plasma I/O adapter
cable (223260)
DB37 male
DB37 female
