Hypertherm ArcGlide THC User Manual

ArcGlide THC Instruction Manual 806450 279
B – ArcGlide THC Serial Communication Installation
Figure 52
DB37F
Customer-supplied connector
DB50 male
Discrete plasma interface
board (141094)
Command THC CNC I/O cable or
customer-supplied CNC I/O cable
4b
3b
1b
3a
1a 2
4a
J5
DB37 female
CNC
ArcGlide control module
Plasma system
RS-422 ports
Command THC CNC I/O cable or
customer-supplied CNC I/O cable
Plasma I/O
cable supplied
by customer
Customer-supplied serial
cable
DB9 female
DB9 male
Plasma I/O
Y adapter cable
(223262)
