OperatiOn
4-36 HPR800XD Auto Gas – 806500
Aluminum
Thickness (mm)
1.5 3 5 6 8 10 12 15 20 25 30 32 38 40 45 50 60 65 70 75 80 100 125 150 160
800A H35 / N
2
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 10.01 N/A 10.62 N/A 12.02 N/A 14.10 15.39 16.64 17.16
600A H35 / N
2
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 7.19 7.39 7.59 7.99 N/A N/A N/A 8.83 8.51 N/A N/A N/A
600A N
2
/ N
2
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 9.16 9.81 10.11 10.62 N/A N/A N/A 11.07 N/A N/A N/A N/A
400A N
2
/ Air
N/A N/A N/A N/A N/A N/A 3.50 3.60 3.70 3.90 4.00 N/A N/A 4.00 N/A 7.60 N/A N/A N/A N/A N/A N/A N/A N/A N/A
400A H35 / N
2
N/A N/A N/A N/A N/A N/A N/A N/A 4.20 4.30 4.30 N/A N/A 4.45 N/A 5.40 7.05 N/A 8.00 N/A 8.15 N/A N/A N/A N/A
400A H35 & N
2
/ N
2
N/A N/A N/A N/A N/A N/A 3.55 3.65 3.80 3.80 4.20 N/A N/A 4.45 N/A 4.55 6.15 N/A 6.85 N/A 7.10 N/A N/A N/A N/A
260A N
2
/ Air
N/A N/A N/A 2.49 2.73 2.97 3.05 2.91 3.05 3.30 N/A 2.87 3.99 N/A N/A 5.66 N/A N/A N/A N/A N/A N/A N/A N/A N/A
260A H35 / N
2
N/A N/A N/A 2.64 2.64 2.62 2.79 3.09 3.30 3.56 N/A 3.29 3.60 N/A N/A 5.37 N/A N/A N/A N/A N/A N/A N/A N/A N/A
200A N
2
/ N
2
N/A N/A N/A N/A 1.78 2.03 2.58 2.54 3.01 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
200A H35 / N
2
N/A N/A N/A N/A 2.44 2.67 2.92 3.18 3.30 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
200A H35 & N
2
/ N
2
N/A N/A N/A N/A 2.79 2.92 3.05 3.30 3.81 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
130A H35 / N
2
N/A N/A N/A N/A 2.70 2.72 2.77 2.36 2.90 1.72 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
130A Air / Air
N/A N/A N/A 2.09 2.09 2.10 2.19 1.91 1.87 2.23 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
130A H35 & N
2
/ N
2
N/A N/A N/A 2.06 2.39 2.73 2.76 2.00 2.90 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
45A Air / Air
1.07 1.10 1.25 1.25 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Metric
Estimated kerf-width compensation – continued
