Parts List
HPR800XD Auto Gas – 806500 6-23
Recommended spare parts
Power supply
Part
Number Description Designator Qty.
003142 Relay: 120 volt, double pole, double throw K1 1
129633 Green power lamp assembly 1
129792 Chopper assembly CH1, CH2, CH3, CH4 1
127039 6" fan: 230 CFM, 115 VAC 50-60 HZ 1
027079 10" fan: 450-550 CFM, 120 VAC 50-60 HZ 1
003149 Relay: Pilot arc, 120 VAC CR1 1
229213 PCB: I/O 1
003218* Contactor CON1 1
003233** Contactor CON1 1
109004 Current sensor: Hall 100 amp, 4 volt CS1, CS2, CS3, CS4 1
229238 Start circuit assembly PCB1 1
008709* Fuse: 20 amp, 500 volt F1, F2 2
108847** Fuse: 7.5 amp, 600 volt F1, F2 2
141030 PCB: Control (Primary power supply) PCB3 1
141144 PCB: Control (Secondary power supply) PCB3 1
041802 PCB: Power distribution PCB2 1
108028 Fuse: 3 amp, 250 volt F5, F6, F7 3
108075 Fuse: 6.3 amp, 250 volt (slow-blow) F1, F2, F3 3
108709 Fuse: 10 amp, 250 volt F4 1
141027 PCB: Pump motor drive PCB7 1
229340 Snubber board 1
229360 Contactor: 500 amp DC 120 VAC COIL Con2, Con3 2
* 200/208, 220 and 240 volt power supplies
** 380, 400, 440, 480 and 600 volt power supplies
Chiller interface console
Part
Number Description Designator Qty.
041897 PCB: Console power distribution 1
008756 Fuse: 5 amp, 250 volt (slow-blow) F1 1
027634 Filter housing (on the rear panel of the cooler) 1
027664 Filter element 1
229235 Flow sensor FS1 1
006113 Check valve: 3/8" FPT 1
229345 Solenoid valve 1
141033 PCB: Cooler sensor 1
229224 Temperature sensor 1
