Hypertherm HyPerformance Plasma HPR800XD User Manual

Maintenance
HPR800XD Auto Gas – 806500 5-43
Pilot arc current levels
The pilot arc current level will vary according to the arc current selected, and the process. See table below.
Pilot arc current
Plasma
gas
30
amps
45
amps
50
amps
80
amps
130
amps
200
amps
260
amps
400
amps
600
amps
800
amps
O
2
25 30 30 30 30 40 40 60 60 60
N
2
25 30 30 30 35 40 40 60 60 60
H35 25 30 30 30 35 40 40 60 60 60
F5 25 30 30 30 35 40 40 60 60 60
Air 25 30 30 30 35 40 40 60 60 60
Transfer current
Plasma
gas
30
amps
45
amps
50
amps
80
amps
130
amps
200
amps
260
amps
400
amps
600
amps
800
amps
O
2
10 10 10 10 15 20 20 30 30 30
N
2
10 10 10 10 15 20 20 30 30 30
H35 10 10 10 10 15 20 20 30 30 30
F5 10 10 10 10 15 20 20 30 30 30
Air 10 10 10 10 15 20 20 30 30 30
