InstallatIon
3-46 HPR800XD Auto Gas – 806500
Work lead
Work lead
Work table
Power supply
Part no. Length Part no. Length
123418 3 m (10 ft) 123996 25 m (82 ft)
023382 4.5 m (15 ft) 123997 35 m (115 ft)
023078 7.5 m (25 ft) 023081 45 m (150 ft)
123994 10 m (35 ft) 023188 60 m (200 ft)
023079 15 m (50 ft) 023815 75 m (250 ft)
123995 20 m (65 ft)
Work lead
(Primary and secondary
power supplies)
Lower frame of work table (typical).
16
16
16
Pilot arc lead
(primary only)
16
Work lead
