Hypertherm HyPerformance Plasma HPR800XD - Chiller Interface Console - 078537

SpecificationS
HPR800XD Auto Gas – 806500 2-7
Chiller interface console – 078537
• Mount the chiller interface console in a horizontal position.
• Allow room to remove the top for servicing.
• Do not mount the chiller interface console on top of the power supply.
355.6 mm
13.88 in
304.8 mm
12.0 in
177.8 mm
7.0 in
279.4 mm
11.0 in
276.2 mm
10.875 in
12.1 kg
26.6 lb
