Parts List
6-24 HPR800XD Auto Gas – 806500
Chiller (PolyScience)
See the Instruction manual that came with the chiller for a more detailed parts list.
Part
Number Description Qty.
040266* Contactor 1
040276* Fuse: 30 amp 1
040278* Fuse: 5 amp 1
040279* Fuse: 6 amp 1
040275** Fuse: 3.5 amp 1
040265*** Contactor 1
040273*** Fuse: 15 amp 1
040272**** Fuse: 1 amp 1
040274**** Fuse: 2.5 amp 1
040277***** Fuse: 4 amp 1
040280 (all voltages) Fuse: 1 amp 1
040267 (all voltages) Contactor 1
040281 (all voltages) Fuse: transformer 1.4 amp 1
040282 (all voltages) Fuse: transformer 3.5 amp 1
040270 Fan: 115 volt, 32 CFM 1
040269 Dual float switch 1
040271 Flow switch 1
040298 Recirculation pump: 1/2 HP, 3PH, 50/60HZ (200-240 volt, 380-460 volt) 1
040299 Recirculation pump: 1/2 HP, 3PH, 60HZ (575-600 volt) 1
040296 Process pump: 1 HP, 3PH, 50/60HZ (200-240 volt, 380-460 volt) 1
040297 Process pump: 1 HP, 3PH, 60HZ (575-600 volt) 1
040295 Valve: Pressure relief valve, 200 psi 1
040301 Sensor: Water pressure transducer 1
040284 Motor: fan, 1140 rpm (200-240 volt, 380-460 volt) 1
040285 Motor: fan, 1140 rpm (575-600 volt) 1
040312 Air filter 3
040322 “Y” strainer for process 1
Ignition console
Part
Number Description Designator Qty.
041817 HFHV Ignition PCB 1
129854 Transformer T1 1
* 200 and 240 volt units
** 380 and 440 volt units
*** 380, 440, 460, 480, 575, and 600 volt units
**** 575 and 600 volt units only
***** 200, 240, 380, 440, 460, and 480 volt units
