OperatiOn
4-70 HPR800XD Auto Gas – 806500
Metric
English
Select
Gases
Set
Preflow
Set
Cutflow
Minimum
Clearance
Equivalent
Material
Thickness
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce
Delay
Time
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Mix
Gas 1
Mix
Gas 2
mm mm Range (mm) mm/m mm Factor % Seconds
H35 N
2
19 51 75 80 32 18 2.0
6
3.0 – 10.0
1835
6.0
200
0.3
8 1515
10 1195
12 3.5 – 10.0 875 7.0 0.5
15 3.8 – 10.0 670 7.6 0.8
20 3.0 – 10.0 305 7.7 180 1.3
Note: Bevel angle range is 0° to 45°.
Stainless steel bevel cutting
H35 and N
2
Plasma / N
2
Shield
130 A
Select
Gases
Set
Preflow
Set
Cutflow
Minimum
Clearance
Equivalent
Material
Thickness
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce
Delay
Time
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Mix
Gas 1
Mix
Gas 2
in in Range (in) ipm in Factor % Seconds
H35 N
2
19 51 75 80 32 18 0.080
1/4
0.12 – 0.40
70
0.24
200
0.3
5/16 60
3/8 50
1/2 0.14 – 0.40 30 0.28 0.5
5/8 0.15 – 0.40 25 0.30 0.8
3/4 0.17 – 0.40 15 0.31 180 1.3
Marking
Select
Gases
Set
Preflow
Set
Cutflow
Amperage
Torch-to-Work
Distance
Marking
Speed
Arc
Voltage
Amps mm in mm/m ipm Volts
N
2
N
2
10 10 10 10 18 2.5 0.10 6350 250 130
Ar N
2
50 10 50 10 15 3.0 0.12 2540 100 75
220738220637 220606220739 220179220656 220571
Flow rates – lpm/scfh
H35 N
2
Preflow 0 / 0 97 / 205
Cutflow 13 / 28 120 / 250
