OperatiOn
HPR800XD Auto Gas 806500 4-99
Aluminum
H35 Plasma / N
2
Shield
200 A
Metric
English
Select
Gases
Set
Preflow
Set
Cutflow
Material
Thickness
Arc
Voltage
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
mm Volts mm mm/m mm Factor % Seconds
H35 N
2
17 43 73 43
8
152
6.4
5000
9.0 140
0.3
10 4400
12
150
3800 0.4
15 3000 0.5
20 159 1450 0.6
Select
Gases
Set
Preflow
Set
Cutflow
Material
Thickness
Arc
Voltage
Torch-to-Work
Distance
Cutting
Speed
Initial Pierce
Height
Pierce Delay
Time
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
Plasma
gas
Shield
gas
in Volts in ipm in Factor % Seconds
H35 N
2
17 43 73 43
5/16
152
0.25
197
0.35 140
0.3
3/8 180
1/2
150
140 0.4
5/8 110 0.5
3/4 159 70 0.6
Marking
Flow rates – lpm/scfh
H35 N
2
Preflow 0 / 0 113 / 240
Cutflow 34 / 72 90 / 190
220762220637 220307220759 220342220346
Select
Gases
Set
Preflow
Set
Cutflow
Amperage
Torch-to-Work
Distance
Marking
Speed
Arc
Voltage
Amps mm in mm/m ipm Volts
N
2
N
2
10 10 10 10 18 2.5 0.10 6350 250 140
Ar N
2
30 10 30 10 20 3.0 0.12 2540 100 66
220340
