Hypertherm HyPerformance Plasma HPR800XD User Manual

7-26
Interface
CNC
(Customer Supplied)
141030
CONTROL BOARD
S301
12
J300
3
4
3 2 1
4
J303A J303B
Serial ID
Dipswitch
Jumper Block
Machine Motion
CNC Interface Cable
Notes:
1) For single system installation set Serial ID (S301), Machine
Motion (J300), J104 & J105 as shown.
Connect customer supplied remote on/off cable in parallel with
the power supply terminals 1&3 of TB2.
Refer to page 3 of the wiring diagram
2) For a multi-system installation set up as described above, set jumpers as shown on the
multi-system interface page
3) The CNC will need a dedicated I/O for each system using the Remote On/Off feature
(contact should be rated for min. 24Vac, 0.5 Amp)
7
RED/BLK
RED
WHT
RED
Gas Console
078533
Gas Power
Cable
Customer Supplied
Remote On/Off
J10 4
21 21
J105
Optional Remote On/Off
TB2
WHT
RED
RED/BLK
RED
6
2
1
1X1
BMD
J2
BTR
J7
RS-232
J9
RS-422
BHST AHST
J3
AMD
J5 J6
RS-422
J10
RS-232 ATR
J8
J1
SV
RIBBON CABLE
Serial isolation board in a Hypertherm Automation controller
1 2 3 4 5 6 7 8
ON
1X7
120 VAC HOT
120 VAC RTN
K1
141144
CONTROL BOARD
S301
12
J300
3
4
3 2 1
4
J303A J303B
Serial ID
Dipswitch
Jumper Block
Machine Motion
7
RED/BLK
RED
WHT
RED
J10 4
21 21
J105
TB2
WHT
RED
RED/BLK
RED
6
2
1
1X1
1 2 3 4 5 6 7 8
ON
1
1X7
2 5 41 2 5 4
PRIMARY/SECONDARY
REMOTE ON/OFF
CABLE
HPR PAC
Dry Cutting System
1 2 43 5 76
51 32 4 76
* If a Hypertherm Automation controller is being used, and there are intermittent communication
failures (PS Link Failure), try removing the jumnpers on J104 and J105 on the control board, and the
termination jumper (J6 or J8) on the serial isolation board in the controler. Only remove
the termination jumper on the serial isolation board that is connected to the HPR
power supply. See figure below for details.
HPR PAC
Dry Secondary Cutting System
1 2 43 5 76
51 32 4 76
4 3 2 1
1
A
4 3 2
A
B
C
D
B
C
D
ELEC SCH:HPR800XD POWER SUPPLY W/AUTO
D
013381
SHEET 22 OF 24
Switch 1 is in the On position
Switches 2-8 are in the Off position
S301
1 2 3 4 5 6 7 8
Dipswitch setting example:
21 3 4
5 6 7 8
ON
ON
