Appendix B – CnC interfACe protoCol
b-14 HPR800XD Auto Gas – 806500
Command table (9 of 14)
ID Command System Description
102 SET_GAS_IO_FROM_PS Manual gas system
Auto gas system
This command will allow the user to turn on or off each output
of the processor. After sending this command, the SYSTEM_
RESET command must be issued to restore the processor state.
The I/O are in the following order:
Note: Use caution when selecting gas valves to make
sure fuel and oxidizers are not mixed together
resulting in a combustible mixture.
Data:
1 = On, 0 = Off for each I/O point
Return value:
1 = accepted, 0 = not accepted
Manual Gas Console
Shield cutflow (SV16)
Calibrate bypass (SV13)
Plasma cutflow 1 (SV14)
Ramp-down valve (SV20)
Shield preflow (SV17)
Plasma preflow (SV18)
Plasma cutflow 2 (SV19)
H35 plasma cutflow 2 (SV12)
Spare valve (SV15)
O
2
shield cutflow (SV4)
Air shield cutflow (SV5)
N
2
shield cutflow (SV6)
Air preflow (SV7)
N
2
preflow (SV8)
Air plasma cutflow 2 (SV9)
Air plasma cutflow 1 (SV1)
O
2
plasma cutflow 1 (SV2)
H35 plasma cutflow 1 (SV3)
O
2
plasma cutflow 2 (SV10)
N
2
plasma cutflow (SV11)
Auto Gas Console
O
2
inlet (SV1)
Air inlet (SV2)
Air inlet 2 (SV3)
H5 inlet (SV4)
H35 inlet (SV5)
F5 inlet (SV6)
Spare out 1 (Spare)
Ramp-down valve (SV16)
Non-XD = Spare out 2, XD = Ar inlet2 (SV15)
Gas 2 no mix (SV14)
Gas 2 mix (SV13)
N
2
mix (SV12)
N
2
inlet 2 (SV11)
Air inlet 3 (SV10)
N
2
inlet (SV9)
O
2
air inlet (SV8)
Non-XD = CH4 inlet, XD = Ar inlet1 (SV7)
Sample:
>1021111111111111111111167<
>1021C4<
