Hypertherm Powermax 65 Operator's Manual

TORCH SETUP
powermax 65/85 Operator Manual 3-53
45A Unshielded Air flow rate - slpm/scfh
Stainless Steel
Hot 147 / 310
Cold 210 / 450
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
0.5
1.5 3.8 250
0.0
9000 121 12700 119
1 9000 121 12700 119
1.5 0.1 9000 121 12700 119
2 0.3 6000 122 12700 119
3
0.4
3250 123 5950 119
4 1900 128 3700 119
6 0.5 700 130 1800 127
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay
Time
Recommended Maximum
Cut
Speed
Voltage
Cut
Speed
Voltage
in in % seconds ipm Volts ipm Volts
26GA
0.06 0.15 250
0.0
350 120 500 119
22GA 350 120 500 119
18GA
0.1
350 118 500 119
16GA 350 121 500 119
14GA 0.2 300 122 500 117
12GA
0.4
150 121 280 119
10GA 100 125 175 119
3/16 in 0.5 42 131 110 120
1/4 in 0.6 25 130 60 129

Hypertherm Powermax 65 Specifications

General

Open Circuit Voltage (OCV)	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Maximum Cut Capacity (Mild Steel)	1" (25 mm)
Input Voltage	200-600 V, 1/3-PH, 50/60 Hz
Output Current	20 – 65 A
Duty Cycle	50% @ 65 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Torch Lead Length	25 ft (7.6 m)
Maximum Cut Capacity (Aluminum)	5/8" (16 mm)
Severance Cut Capacity (Mild Steel)	1-1/4" (32 mm)
Maximum Severance Thickness	1-1/4 in (32 mm)
Gas Type	Air/Nitrogen
Torch Options	Hand Torch, Mechanized Torch
