www.hysecurity.com © 2019 Important Safety Information MX3630-01 Rev. J 13
Gate operator will not automatically cycle the
gate unless an indication that the appropriate
number of external entrapment protection
sensors are connected and operational.
The normally closed (NC) entrapment protection
sensors wired to the Controller’s SENSOR
inputs are monitored using HySecurity software.
Prompts appear on the display requesting specifi c
confi gurations based on the gate operator type.
The following sensors have been shown in
testing to provide the best performance when
installed with HySecurity operators. HySecurity
supports installers who install these sensors. Other
“Compatible Sensors” may meet UL 325 7th
edition requirements but have not been certifi ed
for use with HySecurity operators. Contact the
sensor manufacturer for specifi c recommendations
for use.
CAUTION
External entrapment protection sensors must
have NC sensor outputs and be wired to the
SENSOR COM terminal for monitoring and
powering purposes. Depending on software
version, the sensor becomes powered when
the gate operator’s motor runs or is always
powered when the operator is connected to
AC power.
Table 1. Sensors Tested for Use with HySecurity Operators
Mfg. Part # Mfg. Details Hysecurity Part #
Photo Eyes (Retrorefl ective)
E3K-R10K4-NR Omron 40 ft max range limit MX000999
NIR-50-325 EMX 45 ft max range limit
IRB-RET EMX 53 ft max range limit
E-931-S50RRGQ Seco-Larm 46 ft max range limit
Photo Eyes (Thru-Beam)
IRB-MON EMX 65 ft max range limit MX3990
E-960-D90GQ Seco-Larm 90 ft max range limit
Edge Sensors
Sentir Series ASO Safety
Channel mount, high
profi le
Channel mount, low
profi le
Round, wraparound
Square, wraparound
AS1502-0440-05
AS1502-0430-05
AS1501-0760
AS1501-0790
CPT210-2U-#-T2 Miller Edge
10k resistor termination
(replace # with length
requirement in feet)
Edge Sensor, Converters
(10K to NC Contact)
Hy2NC HySecurity
2-channel edge
converter
MX4018
Edge, Wireless Kits
iGAZE RE Kit
Transmitter
Solutions
50 ft line of sight max
range limit
WEL-200 (kit
with receiver and
transmitter)
EMX
200 ft line of sight max
range limit
Multi-Input Module
The Solution –
MIM-62
Miller Edge 6 inputs to 2 outputs MX3987
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
