i3 International Cortex S243 - Dhcp; DHCP Server; DHCP Statistics

141
Detailed Port Statistics Parameters:
Items
Description
Connector Type
Displays the connector type, for instance, UTP, SC, ST, LC etc.
Fiber Type
Displays the fiber mode. Multi-Mode or Single-Mode.
Tx Central Wavelength
Displays the fiber optical transmitting central wavelength.
Baude Rate
Displays the maximum baud rate of the fiber module supported.
Vendor OUI
Displays the Manufacturer’s OUI code which is assigned by IEEE.
Vendor Name
Displays the name of the manufacturer of the module.
Vendor P/N
Displays the product name of the module.
Date Code
Displays the date the SFP module was made.
Temperature
Displays the current temperature of the SFP module.
Vcc
Displays the working DC voltage of the SFP module.
Mon1 (Bias)
Displays the current Bias of the SFP module.
Mon2 (TX PWR)
Displays the transmit power of the SFP module.
Mon3 (RX PWR)
Displays the receiver power of the SFP module.
DHCP
DHCP Server
A DHCP Server is used to allocate network addresses and deliver configuration parameters to dynamically configured
hosts called a DHCP client.
DHCP Statistics
This page displays the database counters and the number of DHCP messages sent and received by the DHCP server.
To display the DHCP statistics in the web interface:
 Click Monitor / DHCP / Server / Statistics
 Check the Auto-Refresh check box to have the page automatically refresh every 3 seconds.
DHCP Server Statistics Parameters:
Items
Description
Database Counters
Pool
Number of pools
Excluded IP Address
Number of excluded IP address ranges.
Declined IP Address
Number of declined IP Addresses.
