Spanning Tree MSTI Priorities Configuration Parameters:
The bridge instance. The CIST is the default instance which is always active.
Controls the bridge priority. Lower numeric values have better priority. The bridge priority plus
the MSTI instance number, concatenated with the 6-byte MAC address of the switch forms a
Bridge Identifier.
Spanning Tree CIST Ports
When you implement a Spanning Tree protocol on the switch it is necessary to configure the CIST Ports. This section
describes how to inspect the current STP CIST port configurations, and to configure them.
To configure the CIST Ports in the web interface:
Click Configuration / Spanning Tree / CIST Ports
Set all parameters of CIST Aggregated Port Configuration.
Enable or disable the STP then set all parameters of the CIST normal Port configuration.
Click Apply and click the Save icon in the upper right corner to save the settings. Click Reset to cancel. The page
will revert to previously saved settings.
