92
Network Policy Discovery enables the efficient discovery and diagnosis of mismatch
issues with the VLAN configuration, along with the associated Layer 2 and Layer 3
attributes, which apply for a set of specific protocol applications on that port.
Improper network policy configurations are a very significant issue in VoIP
environments that frequently result in voice quality degradation or loss of service.
Policies are only intended for use with applications that have specific 'real-time'
network policy requirements, such as interactive voice and/or video services.
The network policy attributes advertised are:
1. Layer 2 VLAN ID (IEEE 802.1Q-2003)
2. Layer 2 priority value (IEEE 802.1D-2004)
3. Layer 3 Diffserv code point (DSCP) value (IETF RFC 2474)
This network policy is potentially advertised and associated with multiple sets of
application types supported on a given port. The application types specifically
addressed are:
6. Control / Signaling (conditionally support a separate network policy for
the media types above).
A large network may support multiple VoIP policies across the entire organization, and
different policies per application type. LLDP-MED allows multiple policies to be
advertised per port each corresponding to a different application type. Different ports
on the same Network Connectivity Device may advertise different sets of policies,
based on the authenticated user identity or port configuration. It should be noted that
LLDP-MED is not intended to run on links other than between Network Connectivity
Devices and Endpoints, and therefore does not need to advertise the multitude of
network policies that frequently run on an aggregated link interior to the LAN.
Check to delete the policy. It will be deleted during the next save.
ID for the policy. This is auto generated and shall be used when selecting the policies
that shall be mapped to the specific ports.
Intended use of the application types:
1. Voice – For use by dedicated IP Telephony handsets and other similar
appliances supporting interactive voice services. These devices are typically
deployed on a separate VLAN for ease of deployment and enhanced security
by isolation from data applications.
2. Voice Signaling (conditional) - for use in network topologies that require a
different policy for the voice signaling than for the voice media. This
application type should not be advertised if all the same network policies
apply as those advertised in the Voice application policy.
3. Guest Voice - support a separate 'limited feature-set' voice service for
guest users and visitors with their own IP Telephony handsets and
other similar appliances supporting interactive voice services.
4. Guest Voice Signaling (conditional) - for use in network topologies that
require a different policy for the guest voice signaling than for the guest
voice media. This application type should not be advertised if all the same
network policies apply as those advertised in the Guest Voice application
policy.
5. Softphone Voice - for use by softphone applications on typical data centric
devices, such as PCs or laptops. This class of endpoints frequently does not
support multiple VLANs, if at all, and are typically configured to use an
'untagged' VLAN or a single 'tagged' data specific VLAN. When a network
policy is defined for use with an 'untagged' VLAN (see Tagged flag below),
then the L2 priority field is ignored and only the DSCP value has relevance.
6. Video Conferencing - for use by dedicated Video Conferencing equipment
and other similar appliances supporting real-time interactive video/audio
To Next Page
