3. Operation

When the position data is to be changed for the Operation Pattern (PIO Pattern) No. 2, in addition
to the position data items for the forward position and backward position, the position data items for
the changed forward position and changed backward position, are set.

In the case that the CN1 is turned OFF, the position data for the Forward Position turns to be the
data in
1
Forward Position.
In the case of “ON”, the position data for the forward position are the data specifi ed in “
3
Forward
Position”.

In the case that the CN1 is turned OFF, the position data for the forward position turns to be the
data in
0
Backward Position.
In the case of “ON”, the position data for the forward position are the data specifi ed in “
2
Backward Position”.
Position Data Position Velocity Acceleration Deceleration
Pressing
Force
Pressing
Width
Energy-
Saving
Function
0
Backward Position 0.00 50.00 0.1 0.1 0 0 Effective
1
Forward Position 200.00 50.00 0.1 0.1 70 1.00 Effective
2
Backward Position 10.00 50.00 0.1 0.1 0 0 Effective
3
Forward Position 100.00 50.00 0.1 0.1 60 1.00 Effective
