4. Appendix
[2] ASEP
Actuator
series
Type
Feed
screw
Motor
output
No. of
encoder
pulses
Lead
Mounting
direction
Minimum
speed
Maximum speed
Maximum acceleration/
deceleration
Minimum
push
force
Maximum
push
force
Rated
push
speed
[W] [mm] [mm/s] [mm/s] [G] [N] [N] [mm/s]
RCA
(rod
type)
RA3C
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
5
Horizontal/
vertical
6.25 250
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
2.5
Horizontal/
vertical
3.12 125
Energy-saving spec.: 0.2 ---
High acc/dec spec.:0.2 - - -
RGS3C
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
5
Horizontal/
vertical
6.25 250
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
2.5
Horizontal/
vertical
3.12 125
Energy-saving spec.: 0.2 ---
High acc/dec spec.:0.2 - - -
RGD3C
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
5
Horizontal/
vertical
6.25 250
Energy-saving spec.: 0.3 ---
High acc/dec spec.:1.0 - - -
2.5
Horizontal/
vertical
3.12 125
Energy-saving spec.: 0.2 ---
High acc/dec spec.:0.2 - - -
RA3D
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500 0.3
---
---
5
Horizontal/
vertical
6.25 250 0.3
---
---
2.5
Horizontal/
vertical
3.12 125 0.2
---
---
RGS3D
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500 0.3
---
---
5
Horizontal/
vertical
6.25 250 0.3
---
---
2.5
Horizontal/
vertical
3.12 125 0.2
---
---
RGD3D
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500 0.3
---
---
5
Horizontal/
vertical
6.25 250 0.3
---
---
2.5
Horizontal/
vertical
3.12 125 0.2
---
---
RA3R
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500 0.3
---
---
5
Horizontal/
vertical
6.25 250 0.3
---
---
2.5
Horizontal/
vertical
3.12 125 0.2
---
---
RGD3R
Ball
screw
20 800
10
Horizontal/
vertical
12.5 500 0.3
---
---
5
Horizontal/
vertical
6.25
250 0.3
---
--
-
2.5
Horizontal/
vertical
3.12 125 0.2
---
---
