Ensure that the media is properly handled and stored.
Clean the installed storage devices regularly, as recommended.
Specifications
Table 1. Specifications for the 7226 Model 1U3 storage enclosure
Physical Specifications
Width 438 mm (17.5 in.)
480 mm (18.9 in.) Including Right and Left Latch assemblies
Depth 454 mm (17.9 in.)
Height 43 mm (1.69 in.)
Weight 5.1 kg (10.2 lbs.) Empty Enclosure
7.1 kg (15.6 lbs.) Typical Configuration
Power Specifications
kVA 0.047 @ 120 V AC
V AC 100 to 240
Hertz 50 to 60
Btu Maximum (watts) 478 Btu/hr (140 watts) @ 240 V AC
Power Factor 0.75 to 0.9
Altitude Maximum 3058 m (10000 ft.)
Performance Specifications
Dependant on device, media type, and configuration.
Recommended Environment
Environmental Factor Operating Non-operating
Temperature 10 to 40°C
(50 to 104°F)
-40 to 65°C
(-40 to 149°F)
Relative Humidity
(non-condensing)
20 to 80% non-condensing 5 to 95% (excluding rain)
Maximum Wet Bulb 26°C
(79°F)
29°C
(84°F)
Media Drive Environment and Use
IBM's goal is to provide you with a product that you can configure and use reliably. Removable media drives require specific
maintenance and environmental conditions to operate well over time. Using high quality, data grade media, handling and
storing this media properly, operating the removable media drive in a clean environment and keeping the removable media
drive properly cleaned can help you to avoid problems with your IBM product.
Media
Media Handling and Storage
Optical Media Handling and Storage
Environmental Considerations
Tape Drive Cleaning
SAS and USB Hardware Considerations
Microcode Updates
Summary
Media
