limited number of SAS host bus adapters available. It is 3 meters long.
7226 SAS drive features attach to an IBM POWER System SAS port using an external SAS cable that is provided with each SAS
drive feature ordered. Up to four 7226 SAS drive devices may be attached to a single SAS port using a one-to-four Quad
External SAS Cable (Feature Code #5544). The four 7226 SAS drive devices may be installed in more than one 7226 storage
enclosure.
System x does not support 7226 attach through the Quad SAS Cable.
Feature Kit Contents
Feature Kit Contents
FC 5544 contains one Quad External SAS Cable.
Table 1. Feature Code 5544 Contents
Description Part Number Quantity
Quad External SAS Cable 46C2441 1
Figure 1. Contents of FC 5544
The YE1 (2X) miniSAS to miniSAS-HD Cable
The YE1 (2X) miniSAS to miniSAS-HD Cable (Feature Code #5509) allows the user to attach up to two 7226 SAS drive devices
to just one system host bus adapter port. This external cable option is recommended for IBM POWER System customers who
have a limited number of SAS host bus adapters available. It is 3 meters long.
7226 SAS drive features attach to an IBM POWER System SAS port using an external SAS cable that is provided with each SAS
drive feature ordered. Up to two 7226 SAS drive devices may be attached to a single SAS port using a one-to-two YE1 (2X)
miniSAS to miniSAS-HD Cable (Feature Code #5509). The two 7226 SAS drive devices may be installed in more than one 7226
storage enclosure.
System x does not support 7226 attach through the YE1 (2X) miniSAS to miniSAS-HD Cable.
Feature Kit Contents
Feature Kit Contents
FC 5509 contains one YE1 (2X) miniSAS to miniSAS-HD Cable.
Table 1. Feature Code 5509 Contents
Description Part Number Quantity
3M YE1 (2X) miniSAS to miniSAS-HD Cable 46C2901 1
Figure 1. Contents of FC 5509
