RWARNING! NEVER operate the receiver with an
earphone, headphones or other audio accessories at high
volume levels. Hearing experts advise against continuous
high volume operation. If you experience a ringing in your
ears, reduce the volume level or discontinue use.
RWARNING! NEVER connect the receiver directly to
an AC outlet. This may pose a re hazard or result in an elec-
tric shock.
RWARNING! NEVER operate the receiver while dri-
ving a vehicle. Safety driving requires your full attention—any-
thing less may result in an accident.
RWARNING! NEVER throw a battery cell or battery
pack into a re since as internal battery gas can cause an ex-
plosion.
RWARNING! NEVER disassemble the battery pack.
If the battery cell’s internal material (electrolyte liquid) gets
into your eyes, wash your eyes with water and obtain treat-
ment from an eye doctor immediately.
NEVER connect the receiver directly to a power source of
more than 6 V DC. This will damage the receiver.
NEVER connect the receiver to a power source using re-
verse polarity. This will damage the receiver.
NEVER expose the receiver to rain, snow or any liquids.
The receiver may be damaged.
NEVER operate or touch the receiver with wet hands. This
may result in an electric shock or damage the receiver.
NEVER solder the battery cell. This may damage the bat-
tery.
AVOID using or placing the receiver in direct sunlight or in
areas with temperatures below –10°C (+14˚F) or above
+60°C (+140˚F).
AVOID the use of chemical agents such as benzine or al-
cohol in cleaning, as they can damage the receivers sur-
faces.
Even when the receiver power is OFF, a slight current still
flows in the circuits. Remove the battery pack or batteries
from the receiver while not using it for a long time. Otherwise,
the installed battery pack or batteries will become exhausted,
and will need to be recharged.
RESPECT other people’s privacy. Information overheard
but not intended for you cannot lawfully be used in any way.
For U.S.A. only
CAUTION: Changes or modifications to this device, not
expressly approved by Icom Inc., could void your authority to
operate this device under FCC regulations.
ii
PRECAUTION
