Icom IC-R20

11
FREQUENCY AND CHANNEL SETTING
3
■ Mode selection
DD
VFO mode
VFO mode is used for the desired frequency setting within the
frequency coverage.
➥ Push [VFO MHz] to select VFO mode.
What is VFO?
VFO is an abbreviation of Variable Frequency Oscillator. Fre-
quencies for receiving are generated and controlled by the
VFO.
DD
Memory mode/PreSet*/TV*/Weather
†
channels
Memory mode is used for operation of memory channels
which have programmed frequencies. PreSet channels are
used for most-often used frequencies for quick recall.
*Appears only when PreSet channels/TV channels are
programmed via the optional CS-R20.
†
Available for the USA version only.
qPush [MR S.MW] several times to select the channel type.
• Memory/PreSet/TV /Weather channels can be selected in se-
quence
wRotate [R-DIAL] to select the desired channel.
• Only programmed memory channels can be selected.
• Entering keypad directly can be selected the desired memory
channel.
• See p. 26 for memory programming details.
√
µ
MODE
ANL
AFCTSQL
FM
146 100
PSKIP
-DUP
001
DIAL.SEL SWEEP CENTER
T-SCAN SKIP M.N
TONE SET TS
ATT RF GAIN
IC Recorder
123
4560
789
BAND
DUALWATCH MAIN/SUB POWER
VFO
MHz
MODE
SCAN
MR
S.MW
SCOPE
LOCK
REC
AFC
“µ ” and memory channel
number appear.
• Memory mode indication
MR
S.MW
DIAL.SEL SWEEP CENTER
T-SCAN SKIP M.N
TONE SET TS
ATT RF GAIN
IC Recorder
123
4560
789
BAND
DUALWATCH MAIN/SUB POWER
VFO
MHz
VFO
MHz
MODE
SCAN
MR
S.MW
SCOPE
LOCK
REC
AFC
√
MODE
ANL
AFCTSQL
FM
146 560
PSKIP
-DUP
• VFO mode indication
