■ Power ON
➥ Push and hold [ ] for 1 sec. to turn the power ON.
• Push and hold [ ] for 1 sec. to turn the power OFF.
■ Adjusting the volume level
➥ Rotate [VOL] to adjust the volume level.
• If the squelch is closed, push and hold [MONI] while adjusting the
volume level.
• The display shows the volume level while adjusting.
■ Adjusting the squelch level
➥ While pushing and holding [MONI], push [] or [] sev-
eral times to adjust the squelch level.
• “SqL 1” is loose squelch (for weak signals) and “SqL10” is tight
squelch (for strong signals). “SqL 0” is open squelch.
■ Monitor function
This function is used to listen to weak signals or to open
the squelch manually. You can use it without disturbing the
squelch setting, even when mute functions such as the tone
squelch are in use.
➥ Push and hold [MONI] to monitor the operating frequency.
• “ ” blinks while the monitor function is ON.
4
BASIC OPERATION
1
2
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

Icom IC-V80 Specifications

General

Frequency Range	136-174 MHz
Mode	FM
Waterproof	IP54
Dimensions	58 x 112 x 30 mm
Operating Voltage	7.2 V DC
Channels	207 (200 memory channels, 6 scan edges, and 1 call channel)
