Icom IC-V80 User Manual

11
■ Antenna
Insert the antenna into the antenna connector and twist the
antenna to lock it in place.
CAUTION:
•
NEVER HOLD just the antenna when carrying the trans-
ceiver.
• Transmitting without an antenna will damage the trans
-
ceiver.
■ Belt clip
To attach the belt clip:
➥ Slide the belt clip in the direction of the arrow until the belt
clip locks in place, and makes a ‘click’ sound.
To detach the belt clip:
q Remove the battery pack/case from the transceiver, if it is
attached. (p. 2).
w Lift the tab up (q), and slide the belt clip in the direction
of the arrow (w).
ACCESSORIES
1
Belt clip
Battery pack/case
q
w

Icom IC-V80 Specifications

General

Frequency Range	136-174 MHz
Mode	FM
Waterproof	IP54
Dimensions	58 x 112 x 30 mm
Operating Voltage	7.2 V DC
Channels	207 (200 memory channels, 6 scan edges, and 1 call channel)
