Icom IC-V80 User Manual

22
5
■ Subaudible tones
Some repeaters require subaudible tones to be accessed.
Subaudible tones are superimposed over your normal sig-
nal, and must be set in advance.
q Push [FUNC](M) then [SET](8) to enter the Set mode.
w Push [] or [] to select the repeater tone item. (rt)
e Rotate [VOL] to select the desired subaudible tone.
r Push [# ENT] to exit the Set mode.
• Available subaudible tone frequencies (unit: Hz)
67.0
69.3
71.9
74.4
77.0
79.7
82.5
85.4
88.5
91.5
94.8
97.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
159.8
162.2
165.5
167.9
171.3
173.8
177.3
179.9
183.5
186.2
189.9
192.8
196.6
199.5
203.5
206.5
210.7
218.1
225.7
229.1
233.6
241.8
250.3
254.1
D Tone information
Some repeaters require a different tone system to be ac-
cessed.
DTMF TONES
While pushing [PTT], push the desired DTMF keys, [0] to
[9], [MONI](A), [](B), [](C), [VFO/MR/CALL](D), [M](E),
and [# ENT](F), to transmit their assigned DTMF codes.
• The transceiver has 16 DTMF memory channels (p. 35).
1750 Hz TONE
To access some European repeaters, the transceiver must
transmit a 1750 Hz tone burst.
For IC-V80E only
Push [PTT] briefly, push and hold [PTT] again for 1 or 2 sec.
For other transceivers
While pushing [PTT], push and hold either the [] or [] for
1 or 2 sec. See page 36 for details.
✔ CONVENIENT!
Tone scan function:
If you don’t know the subaudible tone used for a repeater,
the tone scan is convenient for detecting the tone frequency.
➥ Push [FUNC](M), and then [T.SCAN](3) to start a tone
scan.
• When the required tone frequency is detected, the scan pauses,
and the tone frequency is temporarily set.
• See page 34 for details of the tone scan function.
5
REPEATER OPERATION
88.5 Hz repeater tone
[VOL]
1
2
3
4
6
7
8
9
10
11
12
13
14
15
16
18
17
19

Icom IC-V80 Specifications

General

Frequency Range	136-174 MHz
Mode	FM
Waterproof	IP54
Dimensions	58 x 112 x 30 mm
Operating Voltage	7.2 V DC
Channels	207 (200 memory channels, 6 scan edges, and 1 call channel)
