ID Technology ClearMark - Internal Connectors

ClearMark™ Installation, Operation & User Manual – Page 109
V 1.S.10 January 2021
V-1.S.1
Internal Connectors
The following table outlines the internal connections of this board:
J302 is the main power connector.
Printer status LEDs:
- J223: LED HEAD-1
- J224: LED HEAD-2
- J225: LED HEAD-3
- J226: LED HEAD-4
The Touch Screen is powered and communicates
through connector J303.
