ID Technology ClearMark - Description of the Printer; Technical Specifications

ClearMark™ Installation, Operation & User Manual – Page 12
V 1.S.10 January 2021
V-1.S.1
Description of the printer
Technical specifications
GENERAL
SIZE (h x w x d)
110x45 x 139.3 x 55.52 mm
Weight
650 grams
Ambient temperature
+ 5º C to + 40º C
(Depending on the ink used)
Relative humidity
20 - 85 % with no condensation
IP Rating
IP 40
ELECTRIC
Power source voltage
Type: Class II
Vin IN: 110 VAC (0.8 Amp) - 240 VAC (0.5 Amp)
System voltage
24 VDC
Electrical consumption
Max 1.25 Amp
Power consumption
Max 30 W
Consumption in stand-by
Without user interface. 2 W
With user interface: 15 W
USER INTERFACE
Optional external screen
10” touchscreen
COMMUNICATIONS
& INPUTS/OUTPUTS
Ethernet
RJ45
USB
USB-A to connect a pen drive
GPIO
Inputs / Outputs
D-SUB 15 HD connector:
23 OPTO PNP Inputs (VDC = 24 V)
CONNECTIONS
DC IN
2.1 Jack
External encoder
D-Sub 15 HD Female (3 row VGA style) *Do not use True VGA connector
External photocell
D-Sub 15 HD Female (3 row VGA style) *Do not use True VGA connector
BCD Inputs
D-Sub 15 HD Female (3 row VGA style) *Do not use True VGA connector
