2: P RODUCT S PECIFICATIONS
2-74 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
■ FC6A-K4A1
■ FC6A-L03CN1
Terminal block type Applicable Connector: FC6A-PMTB11PN02 (screw fastened type),
FC6A-PMSB11PN02 (spring clamp type)
For wiring precautions, see "Input/Output Wiring" on page 3-15.
Terminal block type Applicable Connector: FC6A-PMTB11PN02 (screw fastened type),
FC6A-PMSB11PN02 (spring clamp type)
For wiring precautions, see "Input/Output Wiring" on page 3-15.
PWR
ANALOG
FC6A-K4A1
Q3- Q3+ Q2- Q2+ Q1- Q1+ Q0- Q0+ 0V
24V
: Fuse
0V
24V
FG
Q0+
Q0-
24V DC
OUT0
Q1+
Q1-
OUT1
Q2+
Q2-
OUT2
Q3+
Q3-
OUT3
Terminal No. I/O
+
-
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
+
-
Analog Voltage/
current Input Device
- +
Analog Voltage/
current Input Device
FC6A-L03CN1
NC I1- I1+ NC I0- I0+
B’ B A B’ B A
Q-
RTD
Q+ 0V
24V
PWR
ANALOG
: Fuse
0V
24V
Terminal No. I/O
FG
Q+
I1+
I1-
NC
Q-
I0+
I0-
NC
24V DC
OUT+
NC
OUT-
B
B’
A
B
B’
A
IN0
IN1
NC
+
-
Analog Voltage/
current Input Device
A
B
B’
Resistance
Thermometer
Thermocouple
- +
