FC9Y-B1722 9-13
9: F
UNCTIONAL
M
ODULES
Device Allocation
This section describes the allocation of analog module devices.
Analog Input Module
The detailed device allocation for analog input modules is as follows.
For the parameter setting values, see "Analog Input Parameter Setting Values" on page 9-15.
Channel
Parameter R/W FC6A-J2C1 FC6A-J4A1 FC6A-J8A1 FC6A-J4CN1 FC6A-J8CU1
I/O No.
Input
CH0
Analog input dataR+0+0+0+0+0
Analog input statusR+1+1+1+1+1
CH1
Analog input dataR+2+2+2+2+2
Analog input statusR+3+3+3+3+3
CH2
Analog input data R ― +4 +4 +4 +4
Analog input status R ― +5 +5 +5 +5
CH3
Analog input data R ― +6 +6 +6 +6
Analog input status R ― +7 +7 +7 +7
CH4
Analog input data R ――+8 ― +8
Analog input status R ――+9 ― +9
CH5
Analog input data R ――+10 ― +10
Analog input status R ――+11 ― +11
CH6
Analog input data R ――+12 ― +12
Analog input status R ――+13 ― +13
CH7
Analog input data R ――+14 ― +14
Analog input status R ――+15 ― +15
When use data register for setting parameters, the following data registers are used.
CH0
Signal type R/W +4 +8 +16 +8 +16
Data type R/W +5 +9 +17 +9 +17
Minimum value R/W +6 +10 +18 +10 +18
Maximum value R/W +7 +11 +19 +11 +19
Filter value R/W +8 +12 +20 +12 +20
Thermistor constant
(R0)
R/W ――――+21
Thermistor constant
(T0)
R/W ――――+22
Thermistor constant (B) R/W ――――+23
CH1
Signal type R/W +9 +13 +21 +13 +24
Data type R/W +10 +14 +22 +14 +25
Minimum value R/W +11 +15 +23 +15 +26
Maximum value R/W +12 +16 +24 +16 +27
Filter value R/W +13 +17 +25 +17 +28
Thermistor constant
(R0)
R/W ――――+29
Thermistor constant
(T0)
R/W ――――+30
Thermistor constant (B) R/W ――――+31
CH2
Signal type R/W ― +18 +26 +18 +32
Data type R/W ― +19 +27 +19 +33
Minimum value R/W ― +20 +28 +20 +34
Maximum value R/W ― +21 +29 +21 +35
Filter value R/W ― +22 +30 +22 +36
Thermistor constant
(R0)
R/W ――――+37
Thermistor constant
(T0)
R/W ――――+38
Thermistor constant (B) R/W ――――+39
