FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-1
2: PRODUCT SPECIFICATIONS
This chapter describes the part names and specifications of the modules that make up the FC6A Series MicroSmart.
Various types of modules are available for the FC6A Series MicroSmart, including CPU modules (All-in-One Type, CAN J1939 All-in-
One Type), expansion I/O modules (input modules, output modules, mixed I/O modules), functional modules (analog modules,
PID modules), and option modules (expansion interface module, HMI module, analog cartridges, communication cartridges).
Normal Operating Conditions
The normal operating conditions common to the modules are as follows.
*1 The HMI module (FC6A-PH1) is 0 to 55°C.
Ambient Operating Temperature -10 to+55°C
*1
Ambient Storage Temperature -25 to+70°C (no freezing)
Relative Humidity 10 to 95%, no condensation
Storage Humidity 10 to 95%, no condensation
Pollution Degree 2 (IEC60664-1)
Degree of Protection IP20 (IEC60529)
Atmosphere No corrosive gas
Altitude or Air Pressure
1,013 to 795 hPa (0 to 2,000 m) during operation
1,013 to 701 hPa (0 to 3,000 m) during transport
Installation Location Inside cabinet
Device Class Open equipment
Overvoltage Category II
Vibration Resistance
DIN Rail Mounted
5 to 8.4 Hz half amplitude 3.5 mm, 8.4 to 150 Hz, acceleration 9.8 m/s
2
(1 G), each
direction XYZ, 2 hours (IEC/EN 61131-2)
Panel Mounted
Shock Resistance 147 m/s
2
(15 G), 11 ms, XYZ, 3 axes, 6 directions, 3 times each (IEC 61131-2)
EMC Immunity IEC/EN61131-2, Zone B compatibility
To Next Page
