FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722 9-1
9: FUNCTIONAL MODULES
This chapter provides an overview of each module of the functional modules and the maximum number of modules that can be
connected.
Analog Module
This section describes the configuration of the analog modules, as well as their parameters, device allocations, and WindLDR
configuration methods.
Analog Module Overview
This section provides an overview of the analog modules and describes their types and the maximum number of modules that can
be connected to the CPU module.
Analog modules are available that allow the FC6A Series MicroSmart to directly handle analog data such as voltage, current, and
temperature. There are eight types of analog modules that differ by the number of analog inputs and outputs and the operation
mode. These analog modules can be used by connecting them to the right side of the CPU module. Analog module inputs support
voltage, current, thermocouples, resistance thermometers, and thermistors. Analog module outputs support voltage and current.
To use an analog module, it must be configured in the Module Configuration Editor. For detailed configuration methods, see
"Expansion Module and Cartridge Settings" on page 12-1. For details on the analog module parameter settings, see "Analog
Module Parameter Settings" on page 9-3.
Analog Module List
This section shows a list of the analog modules.
Module
Type
Type No.
Points Input Type Output Type
Inputs Outputs Voltage Current Thermocouple
Resistance
Thermometer
Thermistor Voltage Current
Analog input
module
FC6A-J2C1 2 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
―――――
FC6A-J4A1 4 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
―――――
FC6A-J8A1 8 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
―――――
FC6A-J4CN1 4 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
K/ J/ R/ S/
B/ E/ T/ N/
C
Pt100/
Pt1000/
NI100/
NI1000/
―――
FC6A-J8CU1 8 ―― ―
K/ J/ R/ S/
B/ E/ T/ N/
C
― NTC/PTC ――
Analog output
module
FC6A-K4A1 ― 4 ―――――
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
Mixed analog
I/O module
FC6A-L06A1
4 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
―――――
― 2 ―――――
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
FC6A-L03CN1
2 ―
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
K/ J/ R/ S/
B/ E/ T/ N/
C
Pt100/
Pt1000/
NI100/
NI1000/
―――
― 1 ―――――
0 to 10 V/
-10 to +10 V
0 to 20 mA/
4 to 20 mA
