FC6A S

ERIES

ICRO

MART

-O

YPE

SER

’

ANUAL

FC9Y-B1722 6-13

6: D

EVICES

Special Data Register

Special Data Register Device Addresses

Note: R/W is an abbreviation for read/write.

The notation for the R/W field is as follows.

R/W: The device can be both read from and written to

R: Read-only

W: Write-only

Do not write to data in the area marked as reserved in the special data registers list. Otherwise the system may not operate

correctly.

Warning

Device

Address

Description Update Timing R/W

D8000 Quantity of Inputs When I/O initialized R

D8001 Quantity of Outputs When I/O initialized R

D8002 CPU Module Type Information Power-up R

D8003

D8004

— Reserved — ― -

D8005 General Error Code When error occurred R/W

D8006 User Program Execution Error Code When error occurred R

D8007 — Reserved — ― -

D8008

Calendar/Clock Current Data

(Read only)

Year Every 500 ms R

D8009 Month Every 500 ms R

D8010 Day Every 500 ms R

D8011 Day of the Week Every 500 ms R

D8012 Hour Every 500 ms R

D8013 Minute Every 500 ms R

D8014 Second Every 500 ms R

D8015

Calendar/Clock New Data

(Write only)

Year ― W

D8016 Month ― W

D8017 Day ― W

D8018 Day of the Week ― W

D8019 Hour ― W

D8020 Minute ― W

D8021 Second ― W

D8022

Scan Time Data

Constant Scan Time Preset Value (1 to 1,000 ms) ― W

D8023 Scan Time Current Value (ms) Every scan R

D8024 Scan Time Maximum Value (ms) At occurrence R

D8025 Scan Time Minimum Value (ms) At occurrence R

D8026 Communication Mode Information (Port 1 to Port 3) Every scan R

D8027

D8028

— Reserved — ― -

D8029 System Software Version Power-up R

D8030 Communication Adapter Information Power-up R

D8031 Optional Cartridge Connection Information Power-up R

D8032 Interrupt Input Jump Destination Label No. (I1) ― R/W

D8033 Interrupt Input Jump Destination Label No. (I3) ― R/W

D8034 Interrupt Input Jump Destination Label No. (I4) ― R/W

D8035 Interrupt Input Jump Destination Label No. (I6) ― R/W

D8036 Timer Interrupt Jump Destination Label No. ― R/W

D8037 Number of Connected I/O Modules When I/O initialized R

D8038 to

D8051

— Reserved — ――

D8052 J1939 Communication Error Code Every scan R/W

D8053 to

D8055

— Reserved — ――

D8056 Battery Voltage ― R
