FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
U
SER
’
S
M
ANUAL
FC9Y-B1722 A-1
APPENDIX
This appendix describes information such as a list of FC6A Series MicroSmart types, how to update the software, and how to install
the USB driver.
Type List
This section describes the types of FC6A Series MicroSmart modules, maintenance parts, manuals, and optional cables (sold
separately).
CPU Modules
Type
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Terminal
Specification
Type No.
All-in-One
Type
100-240V AC
24V DC input
shared sink/
source
Relay output, 2 A/point
16 (9/7)
Pluggable
terminal block
(5.08 mm pitch)
FC6A-C16R1AE
24 (14/10) FC6A-C24R1AE
40 (24/16) FC6A-C40R1AE
24V DC
16 (9/7) FC6A-C16R1CE
24 (14/10) FC6A-C24R1CE
40 (24/16) FC6A-C40R1CE
24V DC
24V DC input
shared sink/
source
Transistor sink output
24V DC, 0.5 A/point
16 (9/7)
Pluggable
terminal block
(5.08 mm pitch)
FC6A-C16K1CE
24 (14/10) FC6A-C24K1CE
40 (24/16) FC6A-C40K1CE
Transistor protection source output
24V DC, 0.5 A/point
16 (9/7) FC6A-C16P1CE
24 (14/10) FC6A-C24P1CE
40 (24/16) FC6A-C40P1CE
12V DC
12V DC input
shared sink/
source
Relay output, 2 A/point
40 (24/16)
Pluggable
terminal block
(5.08 mm pitch)
FC6A-C40R1DE
Transistor sink output
12V DC, 0.5 A/point
FC6A-C40K1DE
Transistor protection source output
12V DC, 0.5A/point
FC6A-C40P1DE
CAN J1939
All-in-One
Type
100-240V AC
24V DC input
shared sink/
source
Relay output, 2 A/point
40 (24/16)
Pluggable
terminal block
(5.08 mm pitch)
FC6A-C40R1AEJ
24V DC
FC6A-C40R1CEJ
Transistor sink output
24V DC, 0.5 A/point
FC6A-C40K1CEJ
Transistor protection source output
24V DC, 0.5 A/point
FC6A-C40P1CEJ
12V DC
12V DC input
shared sink/
source
Relay output, 2 A/point
40 (24/16)
Pluggable
terminal block
(5.08 mm pitch)
FC6A-C40R1DEJ
Transistor sink output
12V DC, 0.5 A/point
FC6A-C40K1DEJ
Transistor protection source output
12V DC, 0.5 A/point
FC6A-C40P1DEJ
To Next Page
