A-2 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
Expansion Modules
Input modules
Output modules
Mixed I/O module
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
24V DC input
shared sink/source
—
8 (8/0) FC6A-N08B1 Pluggable terminal block (5.08 mm pitch)
16 (16/0) FC6A-N16B1 Pluggable terminal block (3.81 mm pitch)
16 (16/0) FC6A-N16B3
20-pin MIL connector
32 (32/0) FC6A-N32B3
100-120V AC input — 8 (8/0) FC6A-N08A11 Pluggable terminal block (5.08 mm pitch)
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
—
Relay output, 2 A/point
8 (0/8) FC6A-R081 Pluggable terminal block (5.08 mm pitch)
16 (0/16) FC6A-R161 Pluggable terminal block (3.81 mm pitch)
Transistor sink output
24V DC, 0.5 A/point
8 (0/8) FC6A-T08K1
Pluggable terminal block (5.08 mm pitch)
Transistor protection source output
24V DC, 0.5 A/point
8 (0/8) FC6A-T08P1
Transistor sink output
24V DC, 0.5 A/point
16 (0/16) FC6A-T16K1
Pluggable terminal block (3.81 mm pitch)
Transistor protection source output
24V DC, 0.5 A/point
16 (0/16) FC6A-T16P1
Transistor sink output
24V DC, 0.1 A/point
16 (0/16) FC6A-T16K3
20-pin MIL connector
Transistor protection source output
24V DC, 0.1 A/point
16 (0/16) FC6A-T16P3
Transistor sink output
24V DC, 0.1 A/point
32 (0/32) FC6A-T32K3
Transistor protection source output
24V DC, 0.1 A/point
32 (0/32) FC6A-T32P3
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No. Terminal Specification
24V DC input
shared sink/source
Relay output, 2 A/point
8 (4/4) FC6A-M08BR1 Pluggable terminal block (5.08 mm pitch)
24 (16/8) FC6A-M24BR1 Pluggable terminal block (3.81 mm pitch)
