6: D
EVICES
6-14 FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
U
SER
’
S
M
ANUAL
FC9Y-B1722
D8057 Analog Volume (AI0) Every scan R
D8058 Built-in Analog Input (AI1) Every scan R
D8059 Analog Input Status AI0 Every scan R
D8060 Analog Input Status AI1 Every scan R
D8061 to
D8066
— Reserved — ――
D8067 Backlight ON Time ― R/W
D8068 — Reserved — ――
D8069
Slave 1 Communication Status/Error (When Data Link Master Mode)
Slave Communication Status/Error (When Data Link Slave Mode)
When error occurred R
D8070 Slave 2 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8071 Slave 3 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8072 Slave 4 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8073 Slave 5 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8074 Slave 6 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8075 Slave 7 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8076 Slave 8 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8077 Slave 9 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8078 Slave 10 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8079 Slave 11 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8080 Slave 12 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8081 Slave 13 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8082 Slave 14 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8083 Slave 15 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8084 Slave 16 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8085 Slave 17 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8086 Slave 18 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8087 Slave 19 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8088 Slave 20 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8089 Slave 21 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8090 Slave 22 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8091 Slave 23 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8092 Slave 24 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8093 Slave 25 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8094 Slave 26 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8095 Slave 27 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8096 Slave 28 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8097 Slave 29 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8098 Slave 30 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8099 Slave 31 Communication Status/Error (When Data Link Master Mode) When error occurred R
D8100 Slave Number (Port 1) ― R/W
D8101 — Reserved — ――
D8102 Slave Number (Port 2) ― R/W
D8103 Slave Number (Port 3) ― R/W
D8104 Control Signal Status (Port 1 to 3) Every scan R
D8105 RS232C DSR Input Control Signal Option (Port 1 to 3)
When sending/
receiving data
R
D8106 RS232C DTR Output Control Signal Option (Port 1 to 3)
When sending/
receiving data
R
D8107 to
D8119
— Reserved — ――
D8120
HMI Module Information
Type ID/Status ― R
D8121 System Software Version ― R
D8122
Cartridge Slot 1 Information
Type ID/Status ― R
D8123 System Software Version ― R
Device
Address
Description Update Timing R/W
To Next Page
