9: F UNCTIONAL M ODULES
9-14 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
Input
CH3
Signal type R/W ― +23 +31 +23 +40
Data type R/W ― +24 +32 +24 +41
Minimum value R/W ― +25 +33 +25 +42
Maximum value R/W ― +26 +34 +26 +43
Filter value R/W ― +27 +35 +27 +44
Thermistor constant
(R0)
R/W ――――+45
Thermistor constant
(T0)
R/W ――――+46
Thermistor constant (B) R/W ――――+47
CH4
Signal type R/W ――+36 ― +48
Data type R/W ――+37 ― +49
Minimum value R/W ――+38 ― +50
Maximum value R/W ――+39 ― +51
Filter Value R/W ――+40 ― +52
Thermistor constant
(R0)
R/W ――――+53
Thermistor constant
(T0)
R/W ――――+54
Thermistor constant (B) R/W ――――+55
CH5
Signal type R/W ――+41 ― +56
Data type R/W ――+42 ― +57
Minimum value R/W ――+43 ― +58
Maximum value R/W ――+44 ― +59
Filter value R/W ――+45 ― +60
Thermistor constant
(R0)
R/W ――――+61
Thermistor constant
(T0)
R/W ――――+62
Thermistor constant (B) R/W ――――+63
CH6
Signal type R/W ――+46 ― +64
Data type R/W ――+47 ― +65
Minimum value R/W ――+48 ― +66
Maximum value R/W ――+49 ― +67
Filter Value R/W ――+50 ― +68
Thermistor constant
(R0)
R/W ――――+69
Thermistor constant
(T0)
R/W ――――+70
Thermistor constant (B) R/W ――――+71
CH7
Signal type R/W ――+51 ― +72
Data type R/W ――+52 ― +73
Minimum value R/W ――+53 ― +74
Maximum value R/W ――+54 ― +75
Filter value R/W ――+55 ― +76
Thermistor constant
(R0)
R/W ――――+77
Thermistor constant
(T0)
R/W ――――+78
Thermistor constant (B) R/W ――――+79
Channel
Parameter R/W FC6A-J2C1 FC6A-J4A1 FC6A-J8A1 FC6A-J4CN1 FC6A-J8CU1
I/O No.
