iDect FC6A series User Manual

1: G ENERAL I NFORMATION
1-2 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
HMI module
Expansion I/O module
Analog module
FC6A -
PH 1
Interface specification
1: Communication connector
Module type
PH: HMI module
FC6A -
M08BR1
Output type
R: Relay output (Mixed I/O module only)
K: Transistor sink output
P: Transistor protection source output
None: No output
Input type
A1: 120V AC
B: 24V DC
None: No input
Terminal specification
1: Pluggable terminal block
3: MIL connector
I/O points
08: 8 I/O points
16: 16 I/O points
24: 24 I/O points
32: 32 I/O points
Module type
N: Input module
R: Output module (Relay output)
T: Output module (Transistor output)
M: Mixed I/O module
FC6A -
J4CN1
Input type
None: Voltage/current input
N: Voltage/current/resistance temperature detector input
U: Thermistor/thermocouple input
Maximum resolution
A: 12 bits
C: 16 bits
Terminal specification
1: Pluggable terminal block
I/O points
2: 2 I/O points
4: 4 I/O points
8: 8 I/O points
03: 3 I/O points
06: 6 I/O points
Module type
J: Analog input module
K: Analog output module
L: Mixed analog I/O module
