3: I NSTALLATION AND W IRING
3-2 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
The FC6A Series MicroSmart can be mounted with the following orientation when the operating temperature is 35°C or lower.
The FC6A Series MicroSmart cannot be mounted with the following orientations.
Side Orientation (Use this orientation with an operating temperature of 35°C or lower.)
