FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722 3-31
3: I NSTALLATION AND W IRING
Internal Power Supply Current of the Expansion Modules and Option Modules
Module Type Model
Internal 5 V Line
Current
Internal 24 V Line
Current
Input module
FC6A-N08B1 30 mA ―
FC6A-N16B1 40 mA ―
FC6A-N16B3 40 mA ―
FC6A-N32B3 65 mA ―
FC6A-N08A11 40 mA ―
Output module
FC6A-R081 35 mA 6 mA/point
FC6A-R161 50 mA 6 mA/point
FC6A-T08P1 25 mA 1.5 mA/point
FC6A-T16P1 30 mA 1.5 mA/point
FC6A-T16P3 30 mA 1.5 mA/point
FC6A-T32P3 45 mA 1.5 mA/point
FC6A-T08K1 25 mA 1.5 mA/point
FC6A-T16K1 30 mA 1.5 mA/point
FC6A-T16K3 30 mA 1.5 mA/point
FC6A-T32K3 45 mA 1.5 mA/point
Mixed I/O module
FC6A-M08BR1 30 mA 6 mA/point
FC6A-M24BR1 55 mA 6 mA/point
Analog module
Analog input module
FC6A-J2C1 40 mA ―
FC6A-J4A1 45 mA ―
FC6A-J8A1 40 mA ―
FC6A-J4CN1 50 mA ―
FC6A-J8CU1 45 mA ―
Analog output module FC6A-K4A1 50 mA ―
Analog I/O module
FC6A-L06A1 55 mA ―
FC6A-L03CN1 60 mA ―
PID module
FC6A-F2MR1 65 mA ―
FC6A-F2M1 65 mA ―
Cartridges
Analog cartridge
FC6A-PJ2A ――
FC6A-PJ2CP ――
FC6A-PK2AV 80 mA ―
FC6A-PK2AW 190 mA ―
Communication cartridge
FC6A-PC1 30 mA ―
FC6A-PC3 30 mA ―
HMI module (no installed cartridges) FC6A-PH1 100 mA 15 mA
HMI module + cartridge
FC6A-PH1+FC6A-PJ2A 120 mA 15 mA
FC6A-PH1+FC6A-PJ2CP 120 mA 15 mA
FC6A-PH1+FC6A-PK2AV 200 mA 15 mA
FC6A-PH1+FC6A-PK2AW 300 mA 15 mA
