3: I NSTALLATION AND W IRING
■ HMI Module and Cartridge
Crimping Tool
The following crimping tool can be used with FC6A Series MicroSmart.
Module Type HMI Module Cartridges
Wire Type
UL1007
UL2464
UL1015
UL1007
UL2464
UL1015
Stripping length (mm) 7 5
Wire thickness (mm
2
) 0.14 to 2.5 0.14 to 1.50
Wire
gauge
AWG 24
1-wire
usage
AI 0,25- 6 (3203040) Yes ― Yes ―
AI 0,25- 8 (3203037) Yes ―――
AI 0,25-10 (3241128) ――――
AWG22
1-wire
usage
AI 0,34- 6 (3203053) Yes ― Yes ―
AI 0,34- 8 (3203066) Yes ―――
AI 0,34-10 (3241129) ――――
AWG20
1-wire
usage
AI 0,5- 6 (3200687) Yes ― Yes ―
AI 0,5- 8 (3200014) Yes ―――
AI 0,5- 8 GB (1208966) ― Yes ――
AI 0,5-10 (3201275) ――――
AI 0,5-10 GB (3203150) ――――
2-wire
usage
AI-TWIN 2 x 0,5-8
(3200933)
Yes ―――
AI-TWIN 2 x 0,5-10
(3203309)
――――
AWG18
1-wire
usage
AI 0,75- 6 (3200690) Yes ―――
AI 0,75- 8 (3200519) Yes ―――
AI 0,75-10 (3201288) ――――
AI 1-8 (3200030) ― Yes ――
AI 1-10 (3200182) ――――
2-wire
usage
AI-TWIN 2 x 0,75-8
(3200807)
Yes ―――
AI-TWIN 2 x 0,75-10
(3200975)
――――
AWG16
1-wire
usage
AI 1,5- 6 (3200755) Yes Yes ――
AI 1,5- 8 (3200043) Yes Yes ――
AI 1,5-10 (3200195) ――――
2-wire
usage
AI-TWIN 2 x 1,5-8
(3200823)
――――
Screwdriver
SZS 0.4×2.5 (1205037) ― Yes
SZS 0.6×3.5 (1205053) Yes ―
Tightening torque (N) 0.5 to 0.6 0.22 to 0.25
Tool Name Phoenix Contact Model Number (order number)
Crimping tool CRIMPFOX 6 (1212034)
• Do not touch live terminals. There is a risk of electric shock.
• When powered, the terminals that are connected to external devices may become hot. Do not touch the terminals
immediately after turning the power off.
• Do not touch the power supply terminals immediately after turning the power off. There is a risk of electric shock.
• Insert the wire all the way to the tip of the ferrule and crimp it.
• When connecting stranded wire or multiple wires to a terminal block, use a ferrule. Otherwise there is a risk of wires
becoming disconnected.
• When using single wires, you do not need to use ferrules.
• Single wire assumes the use of one wire. Do not attach two or more wires to the one connector hole.
Caution
