11: SD M
EMORY
C
ARD
11-48 FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
U
SER
’
S
M
ANUAL
FC9Y-B1722
Uploading user program
The user program on the CPU module will be saved to the PC.
1. Click on the toolbar.
The Browse For Folder dialog box is displayed.
2. Enter the destination and the file name and then click OK.
The upload starts.
Note: If the user program is protected, the Password Error dialog box is displayed. Enter the correct password and click OK. For details, see
"User Program Protection" on page 5-50.
This concludes uploading the user program.
Update system software
The CPU module system software will be updated.
1. Click on the toolbar and click Download system software.
The Download system software dialog box is displayed.
The rest of the operation procedure is the same as downloading system software in WindLDR. For details, see the procedure
from step 3 in "Upgrade FC6A Series MicroSmart System Software" on page A-7.
