10 iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual
e8350 Satellite Router Specifications
3.1.2 Power Specifications
Ensure that the installation site can accommodate the power specifications for the e8350
Satellite Router as defined in Table 3.
Altitude
Operating:
Storage:
≤ 10,000 feet (3048m)
≤ 30,000 feet (9144m)
Operational Vibration
(10 minutes per axis)
The e8350 Satellite Router remains operational when exposed to
0.21 grms with the following profile:
Operational Shock The e8350 Satellite Router shall remain operational when exposed
to 10g, 10ms half sine on x, y, z axis.
Table 3. e8350 Satellite Router Power Specifications
Category Description
Input Voltage Range 100 - 240 VAC universal input
Frequency 50 Hz – 60 Hz
AC Power Consumption ≤ 4.0A maximum
DC Power F-Connector TX Out, +24 VDC, 3.5A maximum power supply to BUC or,
TX Out, +48 VDC, 3A maximum power supply to BUC
Table 2. e8350 Satellite Router Mechanical and Environmental Specifications (continued)
Category Description
Frequency Slope PSD
5 to 350 Hz 0 0.0001 g2/Hz
350 to 500 Hz -6 dB/octave
500 Hz 0 0.00005 g2/Hz
BUC Type
(with LNB)
Power at
90 VAC
Power at
254 VAC
2W Ku-Band 1.0A 0.47A
4W Ku-Band 1.17A 0.52A
16W Ku-Band 2.27A 0.87A
2W C-Band 1.05A 0.48A
5W C-Band 1.44A 0.6A
10W C-Band 1.72A 0.69A
