38 iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual
Monitoring LED Status Indicators
4.7.2 Front and Rear Panel LED Status Definitions
The e8350 Satellite Router rear panel status LEDs are defined in Table 16.
Table 16. Front Panel LED Indicators
LED Label LED Color Status
POWER
Off Indicates that AC powered is off or that there
is a power supply problem.
Green Indicates that power is on. The bootloader has
started.
NET
Green Indicates that the remotes have been
acquired into the network.
Flashing Green Indicates that the elements are in network
acquisition.
Yellow Indicates that the downstream SCPC is locked.
Flashing Yellow Indicates that the downstream SCPC is not
locked.
STATUS
Green Indicates normal operation. The DRAM test is
successful.
Flashing Green Indicates that the unit is booting. The DRAM
test is in progress.
Red Indicates a serious fault or failure in software,
hardware, or configuration. May indicate that
the DRAM test failed.
TX
Green Indicates that the transmitter is enabled.
Yellow Indicates that the transmitter is disabled.
RX
Green Indicates that the receiver is successfully
locked to the downstream.
Yellow Indicates that the demodulator is not locked
to the downstream carrier.
CRYPTO Green FIPS mode is enabled.
Off FIPS mode is not enabled.
FAN Off No fan alarm detected.
Red Fan alarm detected.
TEMP Yellow Operating temperature is nearing over
temperature threshold.
Red Operating temperature threshold has been
exceeded.
